Description
Over the bend! Dyneema®-strength with up to 20 times longer service life under alternating bending loads. THE textile davit rope!
Performance
Wire rope-like strength and elongation properties at one tenth of the weight.
Bending fatigue resistance
Outstanding service life in use as a running rope in rope sheaves.
Compatibility
DNV certified davit rope for manned tender boats in direct replacement of wire ropes with increased safety factor.
Diameter
10 mm - 28 mm Ø
Technical data
Elongation at 10% of the breaking load: 0.60 %
| Ø [mm] |
Weight [kg/100 m] |
Bl. real in splice [kN] |
Bl. linear DIN according to EN ISO 2307 [kN] |
|---|---|---|---|
| 10 mm Ø | 5.80 | 96.00 | 106.67 |
| 12 mm Ø | 10.30 | 165.00 | 183.33 |
| 14 mm Ø | 14.70 | 228.00 | 253.33 |
| 16 mm Ø | 19.00 | 270.00 | 300.00 |
| 18 mm Ø | 23.80 | 370.00 | 411.11 |
| 20 mm Ø | 29.10 | 425.00 | 472.22 |
| 22 mm Ø | 34.60 | 500.00 | 555.56 |
| 24 mm Ø | 40.90 | 570.00 | 633.33 |
| 28 mm Ø | 53.10 | 715.00 | 794.44 |
