Low elongation, high strength
Full utilisation of the raw material in the load-bearing core of parallel polyester fibres.
Long service life
Very abrasion-resistant with excellent performance in clam cleats.
A halyard for cruisers
Thanks to its low stretch, Cup is ideal as halyard and control line.
Specification
Diameter: 6mm - 12mm
Cover: Polyester
Core: Parallel Overbraid Polyester
Usage: Halyards / Control Lines
Construction: Twin: core dependent
Technical data
Elongation at 10% of the breaking load: 1.40 %
Ø
[mm] |
Weight
[kg/100 m] |
Bl. real
in splice
[kN] |
Bl. linear DIN
according to EN ISO 2307
[kN] |
| 6 mm Ø |
2.70 |
7.80 |
8.67 |
| 8 mm Ø |
4.50 |
13.00 |
14.44 |
| 10 mm Ø |
7.30 |
22.00 |
24.44 |
| 12 mm Ø |
9.50 |
32.00 |
35.56 |
