Description
Permanently flexible, durable mooring line with balanced characteristics for large yachts.
Comfort
Permanently flexible with balanced elongation properties for comfortable mooring.
Quality
Abrasion-resistant polyester double braid with long service life and very high strength.
Remains dry
Water-repellent, high-quality mooring line for exacting demands.
Diameter
20 mm Ø - 48 mm Ø
Technical data
Elongation at 10% of the breaking load: 2.00 %
| Ø [mm] |
Weight [kg/100 m] |
Bl. real in splice [kN] |
Bl. linear DIN according to EN ISO 2307 [kN] |
|---|---|---|---|
| 20 mm Ø | 30.00 | 85.00 | 94.44 |
| 22 mm Ø | 37.30 | 99.00 | 110.00 |
| 24 mm Ø | 43.40 | 115.00 | 127.78 |
| 26 mm Ø | 51.00 | 135.00 | 150.00 |
| 28 mm Ø | 59.00 | 158.00 | 175.56 |
| 30 mm Ø | 68.00 | 178.00 | 197.78 |
| 32 mm Ø | 78.00 | 198.00 | 220.00 |
| 36 mm Ø | 99.00 | 262.00 | 291.11 |
| 38 mm Ø | 110.00 | 285.00 | 316.67 |
| 40 mm Ø | 121.00 | 326.00 | 362.22 |
| 44 mm Ø | 147.00 | 380.00 | 422.22 |
| 48 mm Ø | 177.00 | 455.00 | 505.56 |
