Quality
Well-balanced polyester double braid with very high service life.
Value for money
Good sheet and universal line for cruisers at a particularly attractive price.
Comfort
Very flexible for comfortable handling, balanced stretch properties.
Specification
Diameters: 6mm - 22mm
Cover: Polyester
Core: Polyester
Usage: Universal
Construction: Twin/Core Dependent
Technical data
Elongation at 10% of the breaking load: 2.00 %
Ø
[mm] |
Weight
[kg/100 m] |
Bl. real
in splice
[kN] |
Bl. linear DIN
according to EN ISO 2307
[kN] |
| 6 mm Ø |
2.60 |
8.00 |
8.89 |
| 8 mm Ø |
4.00 |
13.00 |
14.44 |
| 10 mm Ø |
6.80 |
20.00 |
22.22 |
| 12 mm Ø |
9.30 |
30.00 |
33.33 |
| 14 mm Ø |
13.00 |
37.00 |
41.11 |
| 16 mm Ø |
18.00 |
48.00 |
53.33 |
| 18 mm Ø |
23.40 |
61.00 |
67.78 |
| 20 mm Ø |
30.00 |
85.00 |
94.44 |
| 22 mm Ø |
37.30 |
99.00 |
110.00 |
