Comfort
Permanently flexible with balanced elongation properties for comfortable mooring.
Quality
Abrasion-resistant polyester double braid with long service life and low water absorption.
Style
Bavaria is an absolute classic with an elegant design – a perfect match for well-kept yachts.
Specification
Diameter: 6mm - 18mm
Cover: Polyester
Core: Polyester
Usage: Mooring
Construction: Twin Load Sharing
Technical data
Elongation at 10% of the breaking load: 2.00 %
Ø
[mm] |
Weight
[kg/100 m] |
Bl. real
in splice
[kN] |
Bl. linear DIN
according to EN ISO 2307
[kN] |
| 6 mm Ø |
2.60 |
8.00 |
8.89 |
| 8 mm Ø |
4.00 |
13.00 |
14.44 |
| 10 mm Ø |
6.80 |
20.00 |
22.22 |
| 12 mm Ø |
9.30 |
30.00 |
33.33 |
| 14 mm Ø |
13.00 |
37.00 |
41.11 |
| 16 mm Ø |
18.00 |
48.00 |
53.33 |
| 18 mm Ø |
23.40 |
61.00 |
67.78 |
