Bronze Toggle & Swage

Roll over image to zoom in Click on image to zoom

Elegant Bronze Turnbuckle assembly, supplied with a Threaded Strap Toggle (B18) at one end and Swage Stud (051) at the other
Forged from high strength bronze alloy
High quality polished chromium finish
Stronger than the wire rope
Toggle action gives full articulation in two planes

SKU	Wire Size (Metric)	Wire Size (Imperial)	Thread (UNF)	Fully Open (MM)	Fully Closed (MM)	Fully Open (INCH)	Fully Closed (INCH)	Toggle Width (MM)	Toggle Width (INCH)	Toggle Pin (MM)	Toggle Pin (INCH)
B24-03	3 MM	1/8"	1/4"	232.0	156.0	9.134	6.142	6.4	0.252	6.4	1/4"
B24-144	4 MM	5/32"	1/4"	243.0	167.0	9.567	6.575	6.4	0.252	6.5	1/4"
B24-04	4 MM	5/32"	5/16"	261.0	178.0	10.276	7.008	8.4	0.331	7.9	5/16"
B24-5165	5 MM	3/16"	5/16"	261.0	178.0	10.276	7.008	8.4	0.331	7.9	5/16"
B24-05	5 MM	3/16"	3/8"	284.0	192.0	11.181	7.559	9.9	0.390	9.5	3/8"
B25-55	-	7/32"	3/8"	289.0	197.0	11.378	7.756	9.9	0.390	9.5	3/8"
B24-386	6 MM	-	3/8"	289.0	197.0	11.378	7.756	9.9	0.390	9.5	3/8"
B24-06	6 MM	-	7/16"	316.0	216.0	12.441	8.504	11.5	0.453	11.1	7/16"
B25-386	-	1/4"	3/8"	294.0	202.0	11.574	7.953	9.9	0.390	9.5	3/8"
B25-06	-	1/4"	7/16"	316.0	216.0	12.441	8.504	11.5	0.453	11.1	7/16"
B25-126	-	1/4"	1/2"	343.0	239.0	13.504	9.409	13.1	0.516	12.7	1/2"
B24-7167	7 MM	9/32"	7/16"	323.0	223.0	12.717	8.780	11.5	0.453	11.1	7/16"
B24-07	7 MM	9/32"	1/2"	343.0	239.0	13.504	9.409	13.1	0.516	12.7	1/2"
B24-08	8 MM	5/16"	1/2"	344.0	240.0	13.543	9.449	13.1	0.516	12.7	1/2"
B24-588	8 MM	5/16"	5/8"	415.0	289.0	16.339	11.378	16.3	0.642	16.0	5/8"
B24-10	10 MM	-	5/8"	421.0	295.0	16.575	11.614	16.3	0.642	16.0	5/8"
B25-10	-	3/8"	5/8"	421.0	295.0	16.575	11.614	16.3	0.642	16.0	5/8"
B25-11	-	7/16"	3/4"	537.0	369.0	21.142	14.528	19.1	0.752	18.5	3/4"
B24-12	12 MM	-	3/4"	537.0	369.0	21.142	14.528	19.1	0.752	18.5	3/4"
B25-12	-	1/2"	3/4"	537.0	369.0	21.142	14.528	19.1	0.752	18.5	3/4"
