Performance sheet for Sport Cruisers up to 45 feet
Comfortable handling: Superior flexibility, softness, and grip
Racing ambitions: Extreme strength and exceptionally low stretch
Specification
Diameter: 8-14mm
Cover: Polyester
Core: Dyneema SK78
Usage: Sheets
Construction: Twin: core dependent
Technical data
Elongation at 10% of the breaking load: 0.50 %
Ø
[mm] |
Weight
[kg/100 m] |
Bl. real
in splice
[kN] |
Bl. linear DIN
according to EN ISO 2307
[kN] |
| 8 mm Ø |
4.10 |
28.00 |
31.11 |
| 10 mm Ø |
7.00 |
49.00 |
54.44 |
| 12 mm Ø |
9.60 |
70.00 |
77.78 |
| 14 mm Ø |
13.80 |
85.00 |
94.44 |
